Examples API v1.3

Examples

Test solution with simple geometry and basic paramiters.

Insert box to Revit

Select a type and provide instance paramiters:


height [mm]

i2Bim_box is a generic model family. An Instance is inserted in the default way.


Insert cylinder to Revit

Provide instance paramiters:

radius [mm]
height [mm]

i2Bim_cylinder is a generic model family. An Instance is inserted by picking a point.


Insert table to Revit

Select a type:

i2Bim_table is a furniture family.An Instance is inserted in the default way on the element face.The family is always vertical.


Insert solid to Revit

Select a type:

i2BIM_type_test is a generic model family.An Instance is inserted in the default way.The family dosn't cointains predefined types. The new Family Type is created according to configurator which provide proper type paramiter values.


Insert Electrical Box to Revit

family type

Select a fuse for module 1:

Select a fuse for module 2:

Select a fuse for module 3:

Select a fuse for module 4:

i2BIM_electrical_box is a electrical equipment family. An Instance is inserted in the default way.The family dosn't cointains predefined types. The new Family Type is created according to provide name.


Insert Air Suplay family with connector to Revit

Provide connector parameter:

Flow Out [L/s]

i2BIM_air-supply-unit is a mechanical family. The family is created with instances of child families (defined in parent family). An Instance is inserted in the default way.The family is being put together in runtime then connector are created.


Insert wall type to Revit

Select a type:

The wall type is loaded to the current project.The source project file (*.rvt) cointains prepared in advance types.


Import families from list of categories.

Select a type:

The families from list of Revit categories are imported to the current project.The source project file (*.revit) contains prepared in advance families and theirs types.
